5 Layers Litho Lamination Machine 26KW Flute Lamination Pasting Machine DX-1450

Product Categories

Dongtai Dingxing Machinery Technology Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 5 Layers Litho Lamination Machine 26KW Flute Lamination Pasting Machine DX1450
Brand: DINGXING/DINGYI
Price: 30000 USD

Brand Name : DINGXING/DINGYI

Model Number : DX-1450

Certification : ISO/CE

Place of Origin : CHINA

MOQ : 1

Price : USD 30000-75000/SET

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 30 SET/MONTH

Delivery Time : 30 DAYS

Packaging Details : Meteorological anti-rust film and steel bottom bracket

Color : Customizable

Function : Two sheet lamination

Part Brand : International Professional Leading Brand

Main Market : Europe and North America

Contact Now

DX-1450 Litho Lamination Machine

	DX-1450	DX-1650	DX-1650XL
Max. Size:	*1450mm1450mm**	1650mm*1450mm	1650mm*1650mm
Min. Size:	*400mm450mm**	400mm*450mm	400mm*450mm
Top Sheet GSM:	120gsm—600g/㎡	120gsm—600g/㎡	120gsm—600g/㎡
Bottom Sheet Thickness:	0.5-10mm	0.5-10mm	0.5-10mm
Max. Speed:	30~150m/min	30~150m/min	30~150m/min
Lamination Accuracy:	±1.5mm	±1.5mm	±1.5mm
Total Weight:	7000kgs	7500kgs	7500kgs
Machine Size:	*14056mm2314mm2560mm*	14056mm2514mm2560mm	16525mm2514mm2560mm
Machine Power:	AC380/50HZ/26KW	AC380/50HZ/28KW	AC380/50HZ/28KW
Suitable Paper	Single face(flute A-G), Multi-ply(3-7) corrugated cardboard, grey paperboard, paper board over 300 GSM.

5 Layers Litho Lamination Machine 26KW Flute Lamination Pasting Machine DX-1450
